20w-50 Oil

Discussion in 'Fox 5.0 Mustang Tech' started by Optimus76, Aug 22, 2013.


  1. Grabbin' Asphalt

    Grabbin' Asphalt Mustang Master

    Joined:
    Jun 11, 2013
    Messages:
    1,940
    Showcase:
    25
    Albums:
    1
    Likes Received:
    277
    Trophy Points:
    94
    Location:
    Atlanta, Ga
    I would suppose more open roads in Fl, here in Atlanta we have 285, spaghetti junction and the downtown connector. When you're going through you never know if a 2hr creep along is coming. To top it off the cooling system needs to be in check. But thankfully those extremes have passed the daily commute and from.

    #21
    Last edited: Aug 27, 2013
  2. Grabbin' Asphalt

    Grabbin' Asphalt Mustang Master

    Joined:
    Jun 11, 2013
    Messages:
    1,940
    Showcase:
    25
    Albums:
    1
    Likes Received:
    277
    Trophy Points:
    94
    Location:
    Atlanta, Ga
    I put in a harden oil pump shaft along with a high volume oil pump and it seems to have matched nicely with the 20w-50. I was scared of the winter cause I just wasn't sure but it does real well all together.

    #22
  3. mikestang63

    mikestang63 Mustang Master

    Joined:
    Aug 28, 2012
    Messages:
    4,156
    Showcase:
    20
    Albums:
    1
    Likes Received:
    1,189
    Trophy Points:
    154
    Location:
    In the garage
    I've been to ATL many times. Could never live there as the commute from the Dunwoody/Buckhead area to downtown and back each day takes over an hour and I would end up killing someone.. lol

    However, I take it you've never been to S Florida. The commute on 95 or going to a major city like West Palm, Ft. Lauderdale or Miami rivals Atlanta and it's HOT here. Like 95-100 degrees with 90% humidity. That plays havoc on a motor and cooling system.

    Glad what you have is working for you but like I said, I've run 5w30 dyno and synthetic oils in my cars for decades here with no problems. I bet if you switch to either a 10W or 5W 30 you'll get better MPG and pick up a few HP.

    Like I always say, that's why Baskin Robbins makes 31 flavors..;)

    #23
  4. Grabbin' Asphalt

    Grabbin' Asphalt Mustang Master

    Joined:
    Jun 11, 2013
    Messages:
    1,940
    Showcase:
    25
    Albums:
    1
    Likes Received:
    277
    Trophy Points:
    94
    Location:
    Atlanta, Ga
    I play in a baseball tourney near West Palm every November, but that's flying in riding with peeps from the airport, but they've always been at odd hours. The pan handle is where I've always went otherwise, Destin Fl, PC Beach Fl. They always had those parallel roads that are always open. I'm close to an oil change but with my high volume oil pump, I'm scared :eek: it would be too easy for it. I have heard bad things with those on stock motors and light oil. Would certainly like more HP's & MPG's :shrug:

    #24
  5. MFE92

    MFE92 Active Member

    Joined:
    Aug 26, 2010
    Messages:
    854
    Likes Received:
    177
    Trophy Points:
    54
    Location:
    Phoenix

    The "w" number shows what viscosity the oil behaves like in "winter" temperatures. A 10w-50, 15w-50, 20w-50, all behave like 50-weights at 100C. But they behave like 10, 15, 0r 20-weight oils at sub-freezing temps. Still very thick, because it's so cold, yet thinner than a 50 would be at the same very cold temperature.

    #25
  6. FastDriver

    Mod Dude

    Joined:
    Sep 6, 2001
    Messages:
    3,030
    Showcase:
    42
    Albums:
    3
    Likes Received:
    146
    Trophy Points:
    84
    MFE, I'm well aware. The point I was making was that contrary to the common misunderstanding, a lower "W" multigrade oil is not going to become thinner at lower temperatures.

    yes.
    Kind of...but not exactly

    I hope this doesn't offend you, but that's a very simplistic, and sometimes incorrect, interpretation of a very complex subject. I'll show an example of why, and don't just consider weight because there are other standards that must be met to classify the grade of the oil. If it passes the viscosity/temperature standard, it may still get bumped into another grade because it fails a sheer standard for a given grade.

    Under our normal operating conditions, 0W-40 isn't less than 5W-30 at startup. In other words, it is not thinner. Mobile 1's 0W-40 will actually have more resistance to flow in a cold motor than its 5W-30.

    Some hard data:

    Mobile 1 5W-30 product data sheet
    http://www.mobil.com/USA-English/Lubes/PDS/GLXXENPVLMOMobil1_5W-30.aspx

    Mobile 1 0W-40 product data sheet
    http://www.mobil.com/USA-English/Lubes/PDS/GLXXENPVLMOMobil_1_0W-40.aspx

    At 40* celsius (104*F), which is the lowest temp for which their viscosity is listed, the 5W-30 is thinner (61.7 cSt vs. 75 cSt). At operating temperature, as anyone would expect, the 5W-30 is also thinner (11cST vs. 13.5cSt).

    This website produces a viscosity vs. temperature graph for each oil if you know the information on the product data sheet: http://www.widman.biz/English/Calculators/Graph.html

    It's broken down in 5* C increments, but for the interest of brevity, I'm not going to list the results of every cell. If you want that level of detail, just enter the data from the product sheet into the flash app at the link above.

    Here's the viscosity numbers that it pumped out:

    M1 0W-40
    Temp (C)/ viscosity (cSt) 0W40/ vicsocity (cSt) 5W30
    -35/10804/10939
    -30/6402.7/6279
    -20/2520/2346
    -10/1129/1011
    0/563/490
    10/307/261.7
    20/180.8/151.6
    40/75/61.7
    60/37.4/30.5
    80/21.4/17.4
    100/13.5/11

    So, the results indicate that the 5W-30 oil is thinner than the 0W-40 at any temperature higher than -35*C (-31*F). At that temperature and colder, 0W-40 is finally thinner than 5W-30. Now, I it gets cold here in Germany, but I'm certain I have never started my corvette at or below this temperature.

    This shouldn't be a surprise since you're comparing a 40 weight oil to a 30 weight oil. Now, for what it's worth, I believe from a technical perspective that 5W-30 is the better selection in general at the kind of "freezing" temperatures that I will experience, but it's precisely because the oil is thinner and will flow more easily than the heavier "0W" oil, which I think is contrary to your reasoning. Seems like someone (not you) might argue that the thicker oil offers more protection at low temperature or something, but as you can see above, both oils are much thicker at low temperatures than they are at operating temperatures. So, the oils are obviously more than thick enough to provide adequate protection. More important is how quickly each oil will flow through the lubrication system and build pressure.

    In the older days, oil pumps couldn't generate the pressure to move the oil from the pan when it was too cold. That's not going to happen with either of these oils unless you're in antarctica. So, the entire argument is moot. Bottom line: these oils are very close to each other in cold weather performance.

    In a racing application, we'd be talking about other things (shear strength, new operating temps, high temp areas of the motor, etc...). Then the advantages of a 40 weight oil might really begin to be significant. But even cruising on the autobahn at 200 kph (124mph) for several hours is not going to begin to push the car like 2 back to back hotlaps at the nurburgring.

    Anyway, the point is, there's a lot of things that go into grade. I know you were trying to kind of fill me in on the meaning of the W, but I was aware of the "winter" rating, and didn't want to state something incorrect while at the same time, I wasn't originally planning on giving a class.

    #26
  7. Grabbin' Asphalt

    Grabbin' Asphalt Mustang Master

    Joined:
    Jun 11, 2013
    Messages:
    1,940
    Showcase:
    25
    Albums:
    1
    Likes Received:
    277
    Trophy Points:
    94
    Location:
    Atlanta, Ga
    Interesting data right there :nice:

    #27
  8. MFE92

    MFE92 Active Member

    Joined:
    Aug 26, 2010
    Messages:
    854
    Likes Received:
    177
    Trophy Points:
    54
    Location:
    Phoenix
    I wasn't trying to fill you in on the meaning of the W, and I didn't set out to post a technical treatise on viscosities. Your explanation regarding how quickly the viscosity would change left me a little....cold. :D

    #28
  9. FastDriver

    Mod Dude

    Joined:
    Sep 6, 2001
    Messages:
    3,030
    Showcase:
    42
    Albums:
    3
    Likes Received:
    146
    Trophy Points:
    84
  10. Noobz347

    Noobz347 Stangnet Facilities Maint Tech... Er... Janitor
    Admin Dude

    Joined:
    Jan 5, 1985
    Messages:
    20,589
    Showcase:
    59
    Albums:
    8
    Likes Received:
    2,672
    Trophy Points:
    174
    Location:
    Box behind Walmart
    The thing I think that people often forget is that the first set of numbers (15W for example) are a modification to whatever the weight of the base oil is.

    #30
  11. FastDriver

    Mod Dude

    Joined:
    Sep 6, 2001
    Messages:
    3,030
    Showcase:
    42
    Albums:
    3
    Likes Received:
    146
    Trophy Points:
    84
    Yes, exactly.

    #31
  12. 89stang1

    89stang1 Stroked and Juiced

    Joined:
    Nov 6, 2008
    Messages:
    732
    Showcase:
    63
    Albums:
    3
    Likes Received:
    196
    Trophy Points:
    54
    Location:
    nj
    great info Chris...i like RP and so far my 333 stroker likes it too its been swimming in two quarts of 20/50 and three 10/30 each oil change for 23k miles now, valvetrain sounds quieter and smoother with two 20/50 mixed in i dont mind loses a hp or two for a happy engine

    #32
  13. Noobz347

    Noobz347 Stangnet Facilities Maint Tech... Er... Janitor
    Admin Dude

    Joined:
    Jan 5, 1985
    Messages:
    20,589
    Showcase:
    59
    Albums:
    8
    Likes Received:
    2,672
    Trophy Points:
    174
    Location:
    Box behind Walmart
    I don't know if that's a good thing or not. :shrug: It's not a challenge or anything... I just don't know. :shrug:

    #33
  14. Grabbin' Asphalt

    Grabbin' Asphalt Mustang Master

    Joined:
    Jun 11, 2013
    Messages:
    1,940
    Showcase:
    25
    Albums:
    1
    Likes Received:
    277
    Trophy Points:
    94
    Location:
    Atlanta, Ga

    ....would that equal 15w-40???? :scratch::scratch::scratch:

    #34
  15. mikestang63

    mikestang63 Mustang Master

    Joined:
    Aug 28, 2012
    Messages:
    4,156
    Showcase:
    20
    Albums:
    1
    Likes Received:
    1,189
    Trophy Points:
    154
    Location:
    In the garage
    Well done Sir![​IMG]

    2(20w50) + 3(10w30)= (40w100)+(30w90)=70w190
    70w190/5 quarts= 14w38 ........... or...........................

    (15w40)

    #35
    Grabbin' Asphalt likes this.
  16. FastDriver

    Mod Dude

    Joined:
    Sep 6, 2001
    Messages:
    3,030
    Showcase:
    42
    Albums:
    3
    Likes Received:
    146
    Trophy Points:
    84
  17. Noobz347

    Noobz347 Stangnet Facilities Maint Tech... Er... Janitor
    Admin Dude

    Joined:
    Jan 5, 1985
    Messages:
    20,589
    Showcase:
    59
    Albums:
    8
    Likes Received:
    2,672
    Trophy Points:
    174
    Location:
    Box behind Walmart
    :spit:

    #37
  18. Grabbin' Asphalt

    Grabbin' Asphalt Mustang Master

    Joined:
    Jun 11, 2013
    Messages:
    1,940
    Showcase:
    25
    Albums:
    1
    Likes Received:
    277
    Trophy Points:
    94
    Location:
    Atlanta, Ga
    Assuming it would actually blend or just layer up???

    Like my answer however, ....It's Humpday, Whaut Whaut!!!

    #38
  19. 89stang1

    89stang1 Stroked and Juiced

    Joined:
    Nov 6, 2008
    Messages:
    732
    Showcase:
    63
    Albums:
    3
    Likes Received:
    196
    Trophy Points:
    54
    Location:
    nj


    ha ha ha whats my prize ........i know give ya beotch slap lol even tho now its thursday ...where i get my oil for a special price for me they never have 10w/40 wise assses great math tho lol

    #39
  20. 89stang1

    89stang1 Stroked and Juiced

    Joined:
    Nov 6, 2008
    Messages:
    732
    Showcase:
    63
    Albums:
    3
    Likes Received:
    196
    Trophy Points:
    54
    Location:
    nj


    yes it stays layered!! yes just like when u sqeeze out a load of rock hard turds 20W/50 directly followed by soft serve 10W/30 on top....no blending:crap:

    #40
    Grabbin' Asphalt likes this.
