Cam Decision

Discussion in '1979 - 1995 (Fox, SN95.0, & 2.3L) -General/Talk-' started by elarm1, Aug 13, 2014.


  1. elarm1

    elarm1 Active Member

    Joined:
    Dec 17, 2010
    Messages:
    783
    Likes Received:
    195
    Trophy Points:
    54
    Location:
    N.Va
    Well as you all know, I snatched the motor out of my car to inspect what I thought was some major damage. Turns out that I had a couple of bad lifters. While the engine has been out, I thought it would be a good idea to do a minor rebuild/repaint of the bottom end. Everything is pretty much put together but I have a dilemma. I have two TF cams, one stage one and one stage two. I'm really not set on using either one and also have thought of going custom but then I'd still have two cams sitting around. The motor is a 306 with AFR 165 heads and a V3 that will be sitting off the side of it. What should you guys thing I do?
    #1
  2. 84Ttop

    84Ttop They make new pistons every day, so why worry? SN Certified Technician Mod Dude

    Joined:
    Jul 3, 2009
    Messages:
    3,240
    Likes Received:
    1,336
    Trophy Points:
    144
    Location:
    South Jersey
    Stock pistons or have they been changed at some point?
    #2
  3. elarm1

    elarm1 Active Member

    Joined:
    Dec 17, 2010
    Messages:
    783
    Likes Received:
    195
    Trophy Points:
    54
    Location:
    N.Va
    They are forged summit special flat top with reliefs
    #3
  4. FoxMustangLvr

    FoxMustangLvr Mustang Master

    Joined:
    Oct 15, 2012
    Messages:
    1,051
    Likes Received:
    355
    Trophy Points:
    94
    Location:
    Spokane, Wa
    Get a custom cam and sell the TF cams if you don't want to use either of them.
    #4
  5. GroverDill

    GroverDill GoldMember

    Joined:
    Aug 19, 1999
    Messages:
    4,808
    Likes Received:
    321
    Trophy Points:
    114
    Location:
    Rathdrum ID 83858
    3/4 race cam


    full race is just too much.

    :)
    #5
    tannerc91gt likes this.
  6. hoopty5.0

    hoopty5.0 Mustang Master

    Joined:
    Dec 14, 2010
    Messages:
    2,327
    Likes Received:
    549
    Trophy Points:
    134
    Location:
    SW Houston
    I didn't know this was the IROC forum.

    [​IMG]
    #6
    madmike1157 and f8tlfiveo like this.
  7. mikestang63

    mikestang63 Mustang Master

    Joined:
    Aug 28, 2012
    Messages:
    3,901
    Showcase:
    20
    Albums:
    1
    Likes Received:
    1,096
    Trophy Points:
    144
    Location:
    In the garage
    If you have the PTV clearance I would go with the TFS2. especially with the blower. You will want to check the springs to make sure they are adequate as you will be near .550 with that cam.
    #7
  8. A5literMan

    A5literMan Mustang Master

    Joined:
    Jul 31, 2011
    Messages:
    1,252
    Likes Received:
    334
    Trophy Points:
    94
    Location:
    Illinois
    If you're looking to max out I vote custom. If not use what you got. Stage 1 is very streetable and safe the extra $$ for a tune.??
    #8
  9. elarm1

    elarm1 Active Member

    Joined:
    Dec 17, 2010
    Messages:
    783
    Likes Received:
    195
    Trophy Points:
    54
    Location:
    N.Va
    I had the TFS1 in with no problems but just had a TFS2 sitting around. My gut says get a custom FTI from Ed Curtis but is 340 bucks justifiable?
    #9
  10. elarm1

    elarm1 Active Member

    Joined:
    Dec 17, 2010
    Messages:
    783
    Likes Received:
    195
    Trophy Points:
    54
    Location:
    N.Va
    I had the TFS1 in with no problems but just had a TFS2 sitting around. My gut says get a custom FTI from Ed Curtis but is 340 bucks justifiable? Numbers mean nothing to me. I want a streetable combo that I won't have to worry about. I know I will be pushing some good numbers with the V3 and my combo but 5 or 10 hp's won't kill me
    #10
  11. madmike1157

    madmike1157 the humor is still lost on me SN Certified Technician

    Joined:
    Nov 30, 1999
    Messages:
    3,874
    Albums:
    1
    Likes Received:
    984
    Trophy Points:
    154
    Location:
    Birmingham, al
    What, you just thought about extra stuff you didn't say in your first post, and created an entirely new reply 3 minutes later, just to be sure what needed to be said gets said?

    Instead of editing the first post?
    #11
  12. RangerJoe

    RangerJoe Advanced Member

    Joined:
    Apr 27, 2010
    Messages:
    1,170
    Showcase:
    3
    Albums:
    1
    Likes Received:
    175
    Trophy Points:
    74
    Location:
    Georgia
    It will be more than $340. My FTI was $415 by the time it made it to my door, plus the $300 spring kit he requires you to use. Then you will definitely need pushrods, there's another $120. If you don't need every last bit of performance, stick the TFS 1 in there. The blower will make up for a lot of the performance.

    Joe
    #12
    A5literMan and hoopty5.0 like this.
  13. elarm1

    elarm1 Active Member

    Joined:
    Dec 17, 2010
    Messages:
    783
    Likes Received:
    195
    Trophy Points:
    54
    Location:
    N.Va
    Dag... I didn't realize I messed up the edit. Too much Whiskey last night I guess!!!

    Well that makes more than sense to me. Thats almost a thousand bucks right there! I'll stick my cam that I already have in there right now and keep on pushin!
    #13
  14. 2000xp8

    2000xp8 Mustang Master

    Joined:
    Aug 9, 2003
    Messages:
    5,438
    Likes Received:
    247
    Trophy Points:
    104
    Location:
    NJ
    Normally i like a custom cam. Most builds i see stay at the HCI level for a while, so the extra power is useful if it takes years to get a supercharger.
    BUT, since you have a vortech, not sure it really matters.
    You can get a E cam (example) and stage1 to block splitting power so i just don't see the point in the custom cam and spring change.
    #14
  15. 84Ttop

    84Ttop They make new pistons every day, so why worry? SN Certified Technician Mod Dude

    Joined:
    Jul 3, 2009
    Messages:
    3,240
    Likes Received:
    1,336
    Trophy Points:
    144
    Location:
    South Jersey
    Agreed
    #15
  16. revhead347

    revhead347 I have face herpes.

    Joined:
    Jun 14, 2004
    Messages:
    6,601
    Likes Received:
    283
    Trophy Points:
    124
    Location:
    Acworth, GA
    I'm with RangerJoe, I would stick with the TFS1 cam. I think it will work better with the blower. The Stage 2 starts getting out of blower territory with the overlap. Plus you don't know what the springs are rated for.

    Kurt
    #16
  17. Noobz347

    Noobz347 Stangnet Facilities Maint Tech... Er... Janitor Admin Dude

    Joined:
    Jan 5, 1985
    Messages:
    20,118
    Showcase:
    58
    Albums:
    5
    Likes Received:
    2,544
    Trophy Points:
    174
    Location:
    Box behind Walmart
    That damned Compuserve! :fuss: They ASSURED me that they'd taken them all down before the internet happened. :bang:
    #17
    hoopty5.0 likes this.
  18. Noobz347

    Noobz347 Stangnet Facilities Maint Tech... Er... Janitor Admin Dude

    Joined:
    Jan 5, 1985
    Messages:
    20,118
    Showcase:
    58
    Albums:
    5
    Likes Received:
    2,544
    Trophy Points:
    174
    Location:
    Box behind Walmart
    Can you explain this portion? I am FAR from someone who could recommend a cam and it's because I don't know much about them.
    #18
  19. elarm1

    elarm1 Active Member

    Joined:
    Dec 17, 2010
    Messages:
    783
    Likes Received:
    195
    Trophy Points:
    54
    Location:
    N.Va
    You guys are the chit!!! Thank you guys for clearing up any doubt in my mind!
    #19
  20. tannerc91gt

    tannerc91gt More durable than coconuts and twice as fast

    Joined:
    Nov 30, 1999
    Messages:
    5,187
    Likes Received:
    398
    Trophy Points:
    134
    Location:
    Indiana
