GT500 Mods.. what ya got planned?

Discussion in '2007 - 2014 Shelby GT500 Tech' started by MRaburn, Apr 17, 2007.


  1. MRaburn

    MRaburn Founder Admin Dude

    Joined:
    Nov 30, 1999
    Messages:
    8,742
    Showcase:
    90
    Albums:
    5
    Likes Received:
    122
    Trophy Points:
    114
    Location:
    Auburn, AL
    Let's discuss.

    I talked with C&L and they will have their Mass air, inlet tube and pulley and tune avail soon. Probably the first engine mod I will do. Their pulley will include the snout so you don't have to have a puller.

    Course I've mentioned the glass roof we are working on.

    Exhaust most likely will be the Corsa.

    I will have some mock up renderings tomorrow of the exterior.. ;)

    Chime in... :)
    #1
  2. Kpmonti

    Kpmonti New Member

    Joined:
    Oct 10, 2006
    Messages:
    17
    Likes Received:
    0
    Trophy Points:
    0
    Step 1: Buy shelby Gt500 for somewhere close to MSRP. Step 2. Kenne Bell blower. Step 3: Grin from ear to ear.
    #2
  3. MRaburn

    MRaburn Founder Admin Dude

    Joined:
    Nov 30, 1999
    Messages:
    8,742
    Showcase:
    90
    Albums:
    5
    Likes Received:
    122
    Trophy Points:
    114
    Location:
    Auburn, AL
    She's gettin dressed now... :)

    [​IMG]

    Attached Files:

    #3
  4. brands5.0

    brands5.0 Founding Member

    Joined:
    Jun 25, 2001
    Messages:
    581
    Likes Received:
    0
    Trophy Points:
    17
    Location:
    miami ,florida
    F8LBITE,

    Nice times. Thats the best time i have seen a stock GT500 run besides the run Evan smith made for MM&FF he ran some where in the 12.2. What were the rest of you times 60' 1/8 iam intrested to see also what track. So far i have been
    1.996 12.024 @ 119.82 with mods. I know my car has more in it but the driver needs more seat time
    #4
  5. LSR

    LSR New Member

    Joined:
    Jan 4, 2003
    Messages:
    3
    Likes Received:
    0
    Trophy Points:
    0
    Location:
    Belleville, IL
    My Mods.

    I have already have the JLT Stage 2 setup minus the tune, all parts not installed yet is:

    JLT CAI
    Metco 2.6 pulley & idler pulley
    Spark plugs
    BMR LCA's
    Custom heat shield

    The tune I will purchase from Doug at Bama Chips.

    I already have the Ford Racing (Borla) exhaust installed



    Future Mods:

    Torsen T2R Diff with FRPP 4.10 Gears
    One piece driveshaft
    A set of DR's from whom ever comes out with the stock tire size first.

    :nice:
    #5
  6. 04 BLKCobra

    04 BLKCobra New Member

    Joined:
    May 30, 2007
    Messages:
    8
    Likes Received:
    0
    Trophy Points:
    0
    Location:
    La Mesa
    I have seen the K&N CAI put over 20rwhp at a dyno day I went to a month ago. I have also seen a custom tune give a GT-500 40-50rwhp with no other mods.

    My buddy just purchased a JBA 3" Catback for his GT-500 and it sounds sooo mean. It made 30rwhp over the factory 2.5" setup on his GT-500.

    He purchased it from a place called JBARACING that had tons of them in stock. They sold me my 3" catback for my Cobra a week ago and a guy named mike gave me a great price on my kit.
    #6
  7. brands5.0

    brands5.0 Founding Member

    Joined:
    Jun 25, 2001
    Messages:
    581
    Likes Received:
    0
    Trophy Points:
    17
    Location:
    miami ,florida
    These car pick up tons of power i went from peak of 43Xrwhp, 421 rwtq to 550rwhp and 525 rwtq . With a Evolution Sct, 2.6 pulley, JLT maf intake, and plugs. Some places under the graph i picked up, upto 140 hp. My next mods are MT Et streets and off-road x pipe.
    #7
  8. boostedGTR

    boostedGTR New Member

    Joined:
    May 30, 2007
    Messages:
    25
    Likes Received:
    0
    Trophy Points:
    1
    JBA makes a set of long tubes, H pipe and cat back system for the GT500 - most of the major Mustang shops can get them
    #8
  9. Justin00V6Auto

    Justin00V6Auto Founding Member

    Joined:
    Feb 5, 2000
    Messages:
    211
    Likes Received:
    0
    Trophy Points:
    0
    Location:
    Debary, FL, USA
    I keep telling Lee to get me an intake so I can dyno it, come up with a tune, and post results on the forums. Up until recently there were very few intake options. Now we have the KN, steeda, JLT, PHP, C&L to pick from.

    These cars pick up a TON with a good tune. I have made almost 500 at the wheels with just a tune on an otherwise stock car, but that was a very cold day. Most see 480-490RWHP with a good 93 oct tune. Most come in at 425-440RWHP stock, sometimes 450-460RWHP if its cool enough out. There is a very drastic relationship between spark timing and post-intercooler air temp, anything about 100F causes a sharp drop off in timing.

    LTs don't seem to make much in terms of peak power, even if you pick up 10-20rwhp under the curve they add a lot of noise.

    As one said, with a tune, intake, and 2.6 pulley you can see 540-550RWHP.

    I plan to do tune, intake, pulley on my car. Then comes a bigger blower, and eventually turbos.
    #9
  10. MRaburn

    MRaburn Founder Admin Dude

    Joined:
    Nov 30, 1999
    Messages:
    8,742
    Showcase:
    90
    Albums:
    5
    Likes Received:
    122
    Trophy Points:
    114
    Location:
    Auburn, AL
    Justin,

    We need to tag up on Lee and get a system over to you so we can get a tune done and get a system setup on my GT500. I'll be going to Tulsa in 2 weeks with our car. Think a few mags may cover the car then, would be awesome if we could pull something off by then!
    #10
  11. Justin00V6Auto

    Justin00V6Auto Founding Member

    Joined:
    Feb 5, 2000
    Messages:
    211
    Likes Received:
    0
    Trophy Points:
    0
    Location:
    Debary, FL, USA
    Hey, definitely, got your email. I'll be catching up on that stuff tomorrow, feel free to call if you get a chance 321-206-9369.
    #11
  12. MAD05

    MAD05 New Member

    Joined:
    Oct 31, 2006
    Messages:
    8
    Likes Received:
    0
    Trophy Points:
    0
    These vehicles are amazing...recently had the JBA full system (long tubes, X-pipe, exhaust) installed and tuned to the chime of 513 RWHP...NO OTHER MODS yet on this car
    #12
  13. Justin00V6Auto

    Justin00V6Auto Founding Member

    Joined:
    Feb 5, 2000
    Messages:
    211
    Likes Received:
    0
    Trophy Points:
    0
    Location:
    Debary, FL, USA
    Got a graph? I have worked on some GT500s with exhaust and was not impressed.
    #13
  14. MAD05

    MAD05 New Member

    Joined:
    Oct 31, 2006
    Messages:
    8
    Likes Received:
    0
    Trophy Points:
    0
    Ok, here we go...just got the car back out from the Intake install and re-tune...563 RWHP...more to follow.
    #14
  15. MRaburn

    MRaburn Founder Admin Dude

    Joined:
    Nov 30, 1999
    Messages:
    8,742
    Showcase:
    90
    Albums:
    5
    Likes Received:
    122
    Trophy Points:
    114
    Location:
    Auburn, AL
    Nice numbers.

    I will be installing the C&L system tomorrow. No time for dyno but they are seeing between 60-80 HP with the MAF and Tune.
    #15
  16. devildog92

    devildog92 New Member

    Joined:
    Jun 25, 2007
    Messages:
    1
    Likes Received:
    0
    Trophy Points:
    1
    Location:
    7th Ring of Hell
    NOT A FLAME, but a complement.

    Hey guys:

    You have me intrigued. I am very interested in the 500, and continue to try to get the wife on board with the idea. I have a high hp n/a Vette, and have had 8 mustangs and a s/c lightning, so I have always been a Ford guy until the past few years. The only, ONLY way I'd go Mustang again is a GT500, for sure. I miss the whine I have from my Lightning, and it ONLY made 411rwhp. If these 500's are durable, I mean durable, and I do not have to worry about rear windows falling out, or bad trannys, or hoses falling off the block, and can be modded with a KB, I am back on board, especially after driving an acquaintence's stock 500 the other day and finding Bill Ford is no longer there to ruin the company.

    Y'all convinced me...Good job :)
    #16
  17. HotRodHarry

    HotRodHarry New Member

    Joined:
    Jul 23, 2007
    Messages:
    19
    Likes Received:
    0
    Trophy Points:
    0
    Location:
    New Jersey
    Next are 305/45R/18 Nitto drags ....will go great with the 4.10 gears. Will make them about a 3.93 ratio. Just perfect for the 1/4. And fill in the stock ride height tire to fender gap nicely too
    #17
