Rocker Arm Help

Discussion in '1979 - 1995 (Fox, SN95.0, & 2.3L) -General/Talk-' started by foureyefox347, Nov 21, 2013.


  1. foureyefox347

    foureyefox347 Member

    Joined:
    Nov 6, 2013
    Messages:
    49
    Showcase:
    8
    Albums:
    1
    Likes Received:
    0
    Trophy Points:
    7
    Location:
    Waukesha, Wisconsin
    Ok so I build a 347 and I put ported gt40p heads on and I have a tfs stage 1 cam. now I want to put 1.7 ratio roller rockers so if I gave out the specs of the pistions and the heads is there anyway for me to check or calculate if the valves will hit the piston with out taking that heads back off
    #1
  2. 84Ttop

    84Ttop They make new pistons every day, so why worry? SN Certified Technician Mod Dude

    Joined:
    Jul 3, 2009
    Messages:
    3,214
    Likes Received:
    1,305
    Trophy Points:
    144
    Location:
    South Jersey
    This is something that has to be checked. How would you know if you had .001 or .100 of clearance without checking? The deck height on every block is different among other things. Check to know or cross your fingers and go, up to you :)
    #2
    liljoe07 likes this.
  3. liljoe07

    liljoe07 Active Member

    Joined:
    Feb 18, 2009
    Messages:
    1,179
    Likes Received:
    14
    Trophy Points:
    39
    Location:
    Cartersville,Ga
    X2

    Not to mention the various other things that can be off as well. There are lots of tolerances that can swing either way and stack up against you, or for you. That being said, you can do it with the heads on if you have the right tools.
    #3
  4. mikestang63

    mikestang63 Mustang Master

    Joined:
    Aug 28, 2012
    Messages:
    3,822
    Showcase:
    20
    Albums:
    1
    Likes Received:
    1,057
    Trophy Points:
    144
    Better to check now that risk major damage later. As mentioned, every block and heads are different and things like
    Block deck height
    Head deck thickness
    Head gasket thickness
    Rocker arm ratio
    Cam grind tolerances
    Cam timing
    Cam bore alignment
    Main bore alignment
    Crankshaft throw tolerances
    Crank journal tolerances
    Piston wrist pin tolerances
    Connecting rod tolerances
    Valve spring height
    Bearing clearances
    Push rod length

    .... well you get the idea.... all impact PTV clearance

    Method with head off- preferred

    http://www.enginelabs.com/engine-tech/engine-blueprinting-how-to-check-piston-to-valve-clearance/

    Method with head on

    http://www.cranecams.com/faqview.php?s_id=24
    Last edited: Nov 22, 2013
    #4
  5. foureyefox347

    foureyefox347 Member

    Joined:
    Nov 6, 2013
    Messages:
    49
    Showcase:
    8
    Albums:
    1
    Likes Received:
    0
    Trophy Points:
    7
    Location:
    Waukesha, Wisconsin
    well it looks like the heads are comin off again
    #5
  6. tpstang

    tpstang New Member

    Joined:
    Nov 30, 2011
    Messages:
    6
    Likes Received:
    0
    Trophy Points:
    2
    I have the same situation now, because I just bought a set of heads and want to run trick flow cam. ptv was the biggest question I was dealing with but gave in to pulling the engine down because it just isn't worth the risk.
    #6
  7. Dave2000GT

    Dave2000GT Active Member

    Joined:
    Oct 4, 2005
    Messages:
    130
    Likes Received:
    14
    Trophy Points:
    29
    Location:
    Seattle
    I'd just let it ride, should be fine.
    #7
  8. 84Ttop

    84Ttop They make new pistons every day, so why worry? SN Certified Technician Mod Dude

    Joined:
    Jul 3, 2009
    Messages:
    3,214
    Likes Received:
    1,305
    Trophy Points:
    144
    Location:
    South Jersey
    You buying his valves or something? This is terrible advice!!!!
    #8
    90lxcoupe and Noobz347 like this.
  9. mikestang63

    mikestang63 Mustang Master

    Joined:
    Aug 28, 2012
    Messages:
    3,822
    Showcase:
    20
    Albums:
    1
    Likes Received:
    1,057
    Trophy Points:
    144
    Just wow. I would say that makes the top 10 for 2013 of bad advice.

    tfs1 cam that has the following specs

    Duration @ .050" (degrees) - 221 intake/225 exhaust
    Cam Lift (intake/exhaust) - .312"/.319"
    Lift w/ 1.6 rocker (intake/exhaust) - .499"/.510"
    Lobe seperation (degrees) - 112°

    vs. the stock cam with the following specs
    Duration @ .050 210intake /210 exhaust
    Lift with 1.6 rockers 444/.444
    Lobe seperation 115 degrees

    So take the new lift with the 1.7 RR is
    Intake (.499/1.6) x 1.7 =.530 lift
    Exhaust (.510/1.6) x 1.7 = .542 lift

    Although peak lift has nothing to do with PTV, the increased overlap of the cam and the RR will. With a longer duration and shorter lobe seperation . General rule of thumb is .080" on the intake side, and .100" on the exhaust side. I'd also be making sure his springs are good enough for this lift.
    #9
    Noobz347 likes this.
  10. 84Ttop

    84Ttop They make new pistons every day, so why worry? SN Certified Technician Mod Dude

    Joined:
    Jul 3, 2009
    Messages:
    3,214
    Likes Received:
    1,305
    Trophy Points:
    144
    Location:
    South Jersey
    So with the year coming to an end do we make an official Bad advice of 2013 thread? Just curious..
    #10
  11. mikestang63

    mikestang63 Mustang Master

    Joined:
    Aug 28, 2012
    Messages:
    3,822
    Showcase:
    20
    Albums:
    1
    Likes Received:
    1,057
    Trophy Points:
    144
    @Noobz347 .. top 10 worst advice of 2013 thread? maybe a sticky? lol
    #11
    A5literMan, 90lxwhite and 84Ttop like this.
  12. Noobz347

    Noobz347 Stangnet Facilities Maint Tech... Er... Janitor Admin Dude

    Joined:
    Jan 5, 1985
    Messages:
    19,921
    Showcase:
    58
    Albums:
    5
    Likes Received:
    2,484
    Trophy Points:
    174
    Location:
    Box behind Walmart
    This ^^^

    Please don't run the motor until the clearance check is performed. It seems like a pain in the ass if you've never done it before, but it's really a fairly simple procedure.



    Unless... You're into pain and just wanna see what happens when things wrong. :nonono:
    #12
  13. Dave2000GT

    Dave2000GT Active Member

    Joined:
    Oct 4, 2005
    Messages:
    130
    Likes Received:
    14
    Trophy Points:
    29
    Location:
    Seattle
    They make new pistons every day, so why worry?
    #13
  14. mikestang63

    mikestang63 Mustang Master

    Joined:
    Aug 28, 2012
    Messages:
    3,822
    Showcase:
    20
    Albums:
    1
    Likes Received:
    1,057
    Trophy Points:
    144
    [​IMG]
    #14
    A5literMan likes this.
  15. A5literMan

    A5literMan Mustang Master

    Joined:
    Jul 31, 2011
    Messages:
    1,232
    Likes Received:
    318
    Trophy Points:
    94
    Location:
    Illinois
  16. liljoe07

    liljoe07 Active Member

    Joined:
    Feb 18, 2009
    Messages:
    1,179
    Likes Received:
    14
    Trophy Points:
    39
    Location:
    Cartersville,Ga
    Hehe..... All of the above!
    #16
  17. foureyefox347

    foureyefox347 Member

    Joined:
    Nov 6, 2013
    Messages:
    49
    Showcase:
    8
    Albums:
    1
    Likes Received:
    0
    Trophy Points:
    7
    Location:
    Waukesha, Wisconsin
    yea im pretty sure my springs are rated for that lift and duration i got the alexs parts gt40p springs they say good for .560 lift
    #17
  18. Grabbin' Asphalt

    Grabbin' Asphalt Mustang Master

    Joined:
    Jun 11, 2013
    Messages:
    1,940
    Showcase:
    25
    Albums:
    1
    Likes Received:
    277
    Trophy Points:
    94
    Location:
    Atlanta, Ga
    Lmao:rlaugh:bad advice thread would be Great!!!
