Suspension Upgrades. Front Or Rear 1st?

Discussion in '1979 - 1995 (Fox, SN95.0, & 2.3L) -General/Talk-' started by 90lxwhite, Jul 14, 2014.

  1. 90lxwhite

    90lxwhite I'm kind of a She-Man

    Joined:
    Aug 25, 2011
    Messages:
    2,629
    Likes Received:
    290
    Trophy Points:
    104
    Location:
    Between the Red and Rio
    If I'm not building a purpose built racecar and springs, shocks, and sfc's have been done where do I go next?

    Mike McNasty

    #1
  2. 84Ttop

    84Ttop They make new pistons every day, so why worry?
    SN Certified Technician Mod Dude

    Joined:
    Jul 3, 2009
    Messages:
    3,431
    Showcase:
    37
    Albums:
    1
    Likes Received:
    1,502
    Trophy Points:
    144
    Location:
    South Jersey
    First would be the rear for me. If you are not racing the car at all, you may want to skip upgrading the front all together.

    #2
  3. srtthis

    srtthis the guy doing it does every local racers rear end

    Joined:
    Jul 4, 2009
    Messages:
    3,951
    Likes Received:
    494
    Trophy Points:
    114
    Location:
    in the shop working!
    rear for sure...

    #3
  4. stykthyn

    stykthyn Commander of the snuggie cultists

    Joined:
    Jul 6, 2006
    Messages:
    8,163
    Likes Received:
    602
    Trophy Points:
    163
    Location:
    gainesville
    swap in an IRS. boom! mind blown

    #4
    tamadrummer88 likes this.
  5. 90lxwhite

    90lxwhite I'm kind of a She-Man

    Joined:
    Aug 25, 2011
    Messages:
    2,629
    Likes Received:
    290
    Trophy Points:
    104
    Location:
    Between the Red and Rio
    Would I get much benefit if I just do rear lowers and not the uppers? I know this is extreme newb but are rear lower arms mainly for launching and straight-line performance or would an aftermarket set help improve cornering as well?

    #5
    tamadrummer88 likes this.
  6. 90lxwhite

    90lxwhite I'm kind of a She-Man

    Joined:
    Aug 25, 2011
    Messages:
    2,629
    Likes Received:
    290
    Trophy Points:
    104
    Location:
    Between the Red and Rio
    Outta my ballpark bubba.

    #6
    tamadrummer88 likes this.
  7. stykthyn

    stykthyn Commander of the snuggie cultists

    Joined:
    Jul 6, 2006
    Messages:
    8,163
    Likes Received:
    602
    Trophy Points:
    163
    Location:
    gainesville
    honestly if you are replacing or ugrading your current 8.8 by the time you do gears/axles/control arms with quality parts you are already into the IRS territory. If your goal is to make the car a driver then its the perfect choice.

    #7
  8. 84Ttop

    84Ttop They make new pistons every day, so why worry?
    SN Certified Technician Mod Dude

    Joined:
    Jul 3, 2009
    Messages:
    3,431
    Showcase:
    37
    Albums:
    1
    Likes Received:
    1,502
    Trophy Points:
    144
    Location:
    South Jersey
    For me upper and lowers go hand in hand. The whole assembly really works together so I don't see any benefit in leaving the uppers and replacing the lowers. The stability in general will be greatly improved by replacing both uppers and lowers. The factory rubber bushings and stamped steel arms just don't cut it imho

    #8
    A5literMan likes this.
  9. 90lxwhite

    90lxwhite I'm kind of a She-Man

    Joined:
    Aug 25, 2011
    Messages:
    2,629
    Likes Received:
    290
    Trophy Points:
    104
    Location:
    Between the Red and Rio
    Whoa whoa slow down Maddog. I have 3.73,s in the stock rearend, that and bolt-on suspension parts is as far as I'm going.

    #9
    tamadrummer88 likes this.
  10. 90lxwhite

    90lxwhite I'm kind of a She-Man

    Joined:
    Aug 25, 2011
    Messages:
    2,629
    Likes Received:
    290
    Trophy Points:
    104
    Location:
    Between the Red and Rio
    There are so many posts regarding the negative impact of poly bushings on the axel side in uppers in other than drag applications I was thinking that rubber would be a better choice in that area.

    #10
  11. 84Ttop

    84Ttop They make new pistons every day, so why worry?
    SN Certified Technician Mod Dude

    Joined:
    Jul 3, 2009
    Messages:
    3,431
    Showcase:
    37
    Albums:
    1
    Likes Received:
    1,502
    Trophy Points:
    144
    Location:
    South Jersey
    @stykthyn :stick:@90lxwhite
    @90lxwhite :uzi:@stykthyn hahaha

    You have to take into account the millions of mustangs that were produced. Now factor in the lack of higher quality suspension parts in years past. This yielded a lot of very broken mustangs. The problem here is more so suspension bind and less so poly urethane bushings. Suspension bind will literally tear your car apart no matter how much support or bracing you have. I'm by no means the expert when it comes to poly urethane suspension parts but you will want to look towards some of the higher end brands here. You truly get what you pay for here and I'm sure @Sharad can chime in with a knowledgeable recommendation.

    #11
    Sharad likes this.
  12. rbohm

    Founding Member

    Joined:
    Apr 13, 2002
    Messages:
    6,407
    Likes Received:
    272
    Trophy Points:
    124
    Location:
    tucson,az
    well said. when upgrading the rear suspension on a fox body, you have to first decide what you ultimate goals for the car are. are you wanting to cut corners, as well as go down the drag strip, or do you want straight line performance to the detriment of all else? if all you are looking for is straight line performance, then it doesnt matter of the suspension binds in corners or not.

    on the other hand if you are looking for cornering prowess, you must take into account any possible suspension bind and eliminate it as much as possible. now you can do this in a few ways again depending on the ultimate use of the car. if this is a street car that will see time in autocross, then you want a supple suspension with lots of grip. that generally means stock upper arms and bushings, and aftermarket lower arms with a solid bushing at one end, and a spherical bearing at the other.

    of course the ultimate set up, imo, is eliminate the upper arms, install a torque arm and panhard bar, and good aftermarket lower arms. that way you eliminate all suspension bind, you set the pinion angle and lock it in, and you set the side to side location and lock it in as well. with this set up though you do have to eventually upgrade the front suspension, but that can wait until you are ready.

    #12
  13. stykthyn

    stykthyn Commander of the snuggie cultists

    Joined:
    Jul 6, 2006
    Messages:
    8,163
    Likes Received:
    602
    Trophy Points:
    163
    Location:
    gainesville
    Then what exactly are you searching for here? Torque arm and panhard bar? What about your setup are you trying to improve.
    - sir lose-a-lot

    #13
  14. tamadrummer88

    tamadrummer88 Active Member

    Joined:
    Aug 19, 2005
    Messages:
    602
    Likes Received:
    77
    Trophy Points:
    39
    Location:
    Aloha State
    A good upgrade next would be your face.

    #14
  15. stykthyn

    stykthyn Commander of the snuggie cultists

    Joined:
    Jul 6, 2006
    Messages:
    8,163
    Likes Received:
    602
    Trophy Points:
    163
    Location:
    gainesville
    [​IMG]

    #15
  16. 90lxwhite

    90lxwhite I'm kind of a She-Man

    Joined:
    Aug 25, 2011
    Messages:
    2,629
    Likes Received:
    290
    Trophy Points:
    104
    Location:
    Between the Red and Rio
    I'm looking to improve the handling both straight line and cornering. I'm not looking to (can't) spend $5k. I'm trying to build a car that will be on par or close to the performance of a more modern sports car that doesn't have a chuckwagon like ride. No auto x, maybe one or 2 trips to the drags. The current arms have over 300k miles.
    Eat my pudding pop Bill

    #16
  17. stykthyn

    stykthyn Commander of the snuggie cultists

    Joined:
    Jul 6, 2006
    Messages:
    8,163
    Likes Received:
    602
    Trophy Points:
    163
    Location:
    gainesville
    Have you done springs yet? When I was having roll issues that was the ticket.

    #17
  18. stykthyn

    stykthyn Commander of the snuggie cultists

    Joined:
    Jul 6, 2006
    Messages:
    8,163
    Likes Received:
    602
    Trophy Points:
    163
    Location:
    gainesville
    Have you done springs yet? In my experience you won't find a set up that's good for both but in a mostly street car a stiffer set of lowering springs is where it's at. Follow that with a k member brace to support the subframes and I think you will be pleasantly surprised.

    #18
  19. tamadrummer88

    tamadrummer88 Active Member

    Joined:
    Aug 19, 2005
    Messages:
    602
    Likes Received:
    77
    Trophy Points:
    39
    Location:
    Aloha State
    I do not want your splendiferous pudding pop.

    #19
    stykthyn likes this.
  20. John Dirks Jr

    John Dirks Jr Active Member

    Joined:
    Jun 28, 2013
    Messages:
    527
    Likes Received:
    53
    Trophy Points:
    39
    Location:
    Maryland
    Everyone always slams it. Dare to be different and rake it. Leave the rear stock height and lower the front a bit.

    #20
    tamadrummer88 likes this.
