Tach Install

Discussion in 'Fox 5.0 Mustang Tech' started by Buck_92 fox, Aug 6, 2014.


  1. Buck_92 fox

    Buck_92 fox New Member

    Joined:
    Aug 6, 2014
    Messages:
    3
    Likes Received:
    0
    Trophy Points:
    1
    image.jpg I need help. I have a 92 mustang lx and I'm trying to install a APC tach with shift light. I'm honestly confused. If anyone knows how to install help is greatly appreciated. Thanks

    #1
  2. RacEoHolic330

    RacEoHolic330 I like to dress like a pretty girl SN Certified Technician

    Joined:
    Mar 5, 2003
    Messages:
    3,502
    Likes Received:
    698
    Trophy Points:
    153
    Location:
    Allentown, PA
    I tried to link to a diagram but it won't work for whatever reason. Google image search 'tach install' and you will get what you need. It's very easy to do.

    #2
  3. Buck_92 fox

    Buck_92 fox New Member

    Joined:
    Aug 6, 2014
    Messages:
    3
    Likes Received:
    0
    Trophy Points:
    1
    I got the tach to light up but now the problem is getting signal to it from the coil I have tried hooking it to the tan wire with a yellow tracer but no signal. Any ideas??

    #3
  4. jrichker

    jrichker StangNet's favorite TOOL SN Certified Technician Founding Member

    Joined:
    Mar 10, 2000
    Messages:
    21,745
    Likes Received:
    383
    Trophy Points:
    134
    Location:
    Dublin GA
    Typically for tach installation, there are 4 wires: The wire colors given here are for wires on the car, not for the tach. The tach wires may be different colors.
    1). Switched power from the ignition - tap the red/green wire on ignition coil.
    2.) Illumination - tap the light blue/red wire in the radio mount area.
    3.) Tach signal - tap the dark green/yellow wire on the ignition coil.
    4.) Ground.- find a clean, shiny, bare metal spot under the dash or in the radio mount area.

    #4
  5. Buck_92 fox

    Buck_92 fox New Member

    Joined:
    Aug 6, 2014
    Messages:
    3
    Likes Received:
    0
    Trophy Points:
    1
    I don't see a green/yellow wire on coil I have a tan/yellow and a red/green. I've tried hooking it up to the tan/yellow wire but no signal...

    #5
  6. jrichker

    jrichker StangNet's favorite TOOL SN Certified Technician Founding Member

    Joined:
    Mar 10, 2000
    Messages:
    21,745
    Likes Received:
    383
    Trophy Points:
    134
    Location:
    Dublin GA
    Sorry, I missed the fact that you had a 92, the wiring colors are different, The tan/yellow is the correct wire to use for the tach signal. If you wired up everything else correctly, the tach doesn't work...

    #6
