Well, i mounted my coil last night, and since i mounted my MSD 6AL right next to it, i decided to figure out how to wire it up. 4 beers later, i had 3 wires connected and a good buzz. So i decided to call it a night before i cut something id regret in the morning.
The car is Carb'd, Has the MSD Billet Distributor, The Blaster SS coil, and this is where im at so far....
I got the small orange wire and the small black wire hooked up to the coil per the instructions. I read where it said to ground the heavy black wire to the block, so i used the ground bolt on the timing cover. I have a question about this though.... The timing cover is aluminum...how good of a ground will that make?
Also, if that wont be a sufficient ground, can i cut and extend the ground wire to a different place on the block without fear of the ground wire being too long? Should i ground it to the frame first then to the block??
The white wire (per the instructions) said its a trigger wire. I had to re-read this part several times over because it got confusing. In one section of the manual, it states that its for like a magnetic pickup, and in another section, it talks about how you can use it for a tach.. i see that there is a tach port on the other side of the MSD, so can i use the white wire for the tach and leave the other one open, or am i reading this wrong?
The heavy red wire says it should be mounted to a 12v source, like the battery or the positive side of the starter solenoid. (My battery is in the hatch) If i remember correctly form pictures, it should be mounted on this side, correct???
View attachment 390107
I believe that the only other wire i have left would be the small red wire, which i believe is supposed to be hooked up to a key-on source. Anyone have any good ideas of where to wire that thing into?
Thanks in advance for any help!
