Looking for opinion on front coilovers

Mstng93SSP

You have a nice rear end there Dave.
15 Year Member
Nov 29, 1999
2,362
2,674
184
Mililani, Hawaii
My 1993 coupe currently has Bilstein front struts and rear shocks. I have Maximum Motorsports caster camber plates, and I am running the Eibach pro kit springs. On the rear I have Maximum Motorsports adjustable control arms (where you can adjust ride height via the spring perch). I am considering switching over to the maximum motorsports front coilovers. My car currently rides o.k., but I feel I will have better ride quality and handling with the coilovers. Will it be a noticeable enough difference to justify the cost (will be about $400)? Car is strictly a street car. I feel like it will and since the car already has the bilsteins and the caster camber plates it's not that much of a jump to go with the coilovers.

Thanks for any input.

Chris


  • Sponsors(?)


Mustang5L5

Put lubricant all over the balls
Mod Dude
Feb 18, 2001
36,524
12,477
224
Massachusetts
Yes, I was pleasantly surprised to see how much better the car rode when I changed to coil overs. It really did make a difference.

I went with 250lb front springs and then MMS recommended rear H&R conventional springs

  • Like
Reactions: 1 user

bird_dog0347

still married haven't seen testicles in years
5 Year Member
Jun 7, 2012
1,196
1,003
154
41
Little Elm, TX
Mine was such a long transition that I didn't drive it for months while working on it but even with stiffer springs on the coil overs than I had before them, it's still a better ride!


stanglx2002

CT Material here
Mod Dude
Jul 7, 2005
1,532
1,152
164
I didn't do the bumpsteer on the car currently so I would say it's not required but I plan to add it soon due to lowering the car quite a bit. The ride is so much better than stock coils. I run pretty stiff springs at 350lb bit the ride quality is that much better IMO.

  • Like
Reactions: 1 user

Steel1

Mustang Master
Aug 18, 2017
1,419
691
143
52
Connecticut
I went with Strange front coil overs, 250lb springs, tubular control arms and bumpsteer kit.
I didn't use a gauge to dial it in the bumpsteer (although that's the best way) just got everything parallel
and it made a big difference.

  • Like
Reactions: 1 user

2000xp8

SN Certified Technician
Aug 8, 2003
7,211
1,243
194
NJ
I use their kit with 275lb springs.
Right quality is better.
Switch the rears to H&R springs when you do the coil overs. That was the real difference changer in ride quality. With what eibach and others do with the springs to lower the cars, one would think you have to stiffen the hell out of them to get them to work, apparently that's not how it works.

For bumpsteer, you have to have the car aligned, measure bump steer, adjust and have it aligned again.
My plan is to parallel things like steel1, if it feels good after an alignment, i'll leave it. If not, I have access to the tool and i'll measure.


Mustang5L5

Put lubricant all over the balls
Mod Dude
Feb 18, 2001
36,524
12,477
224
Massachusetts
If you set the arms parallel, make sure you reference the imaginary line between the pivot point of the balljoint and the control arm bushing. There is a slight difference in this line vs using the body of the A-arm.

  • Like
Reactions: 1 user

FoxMustangLvr

I love my Pimp
SN Certified Technician
Oct 14, 2012
4,971
3,529
194
45
Spokane, Wa
I have the MM coil overs with a 175# spring (MM recommendation) with Tokico Illumina 5 way adjustable front struts. I wanted good ride comfort with good street performance. This setup paired out back with Cobra IRS and IRS stock springs and Bilsteins is an awesome ride and handles great in the turns.

I did everything MM told me to do.

  • Like
Reactions: 2 users

tim4698

Member
Jun 16, 2019
13
1
13
42
Kansas City, MO
I went from terrible shocks and springs the previous owner installed for drag racing (and without a sway bar) to the MM coilover package with 350# front and 250# rear springs. The car handles exceptionally well, but also lets you know how terrible the roads are that you didn't notice before. I actually pulling these springs for track only and moving to more of a 250# front and ???# rear soon so I can enjoy the drive and not wear whatever I'm drinking.


Mustang5L5

Put lubricant all over the balls
Mod Dude
Feb 18, 2001
36,524
12,477
224
Massachusetts
MM recommends the rear coil over spring rates be 150-125 lb less than front.

Lowest rate rear spring they have is 175#.

That really means if you want to keep rear coil overs, you’ll have to use 175# rear with 300-325# front springs. Any less will require a conventional spring setup.

  • Like
Reactions: 1 user

FoxMustangLvr

I love my Pimp
SN Certified Technician
Oct 14, 2012
4,971
3,529
194
45
Spokane, Wa
MM recommends the rear coil over spring rates be 150-125 lb less than front.

Lowest rate rear spring they have is 175#.

That really means if you want to keep rear coil overs, you’ll have to use 175# rear with 300-325# front springs. Any less will require a conventional spring setup.
Exactly. I wanted to buy coil overs for my IRS and MM said NO! I love their honesty and they set me up right. They recommended the stock IRS spring with a coil cut to get the ride height that I desired. It all worked perfectly. It's all about pairing the front and back.

I would've had to get a way stiffer spring up front in order to get coil overs out back which would've resulted in a very rigid suspension setup.
The roads are :poo:ty where I live due to freezing winters so ride comfort is priority #1 for me.


Mustang5L5

Put lubricant all over the balls
Mod Dude
Feb 18, 2001
36,524
12,477
224
Massachusetts
Exactly. I wanted to buy coil overs for my IRS and MM said NO!

Same here. I Was going to do C/Os on all 4 corners until I talked to MM about what i wanted and how I wanted street manners. Totally happy with the setup I have now.

Mine is 250# front and a 275-300# conventional spring in the rear
