Progress Thread Wanting upgrade advice for 350+ rwhp

Craigb79

New Member
May 17, 2020
4
0
1
34
Surrey bc
Hey guys,
I have a 2007 mustang 4 0L and I'm looking for some advice on which upgrades and in what order I should do then.
When I bought the car it had a airaide CAI installed.
I did a gt rear end 8.8 swap from a 2008 gt
And installed a pypes dualexhaust conversion

Obviously my next step will be headers. I kind of want long tubes. But also know if I want to see these numbers I will need bost.
My plan was to get eventually get the modbox kit Nd take N Eaton m90 super charger out of a Thunderbirds.
But if anyone has any suggestions that dont involve me patience g 5k+ for a procharger that would be great.

I'm not going to buy a v8 at this point. So just having fun with it and making it mine is the goal.

HELP ME REACH 350 RWHP

THANK YOU

  • Sponsors(?)


Noobz347

Stangnet Facilities Maint Tech... Er... Janitor
Admin Dude
Jan 4, 1985
28,971
10,939
224
Box behind Walmart
www.stangnet.com
I think you should just drive it and not worry about how much power it makes.

If you don't want to fork over 5k for a supercharger kit plus and additional 500 or so for a tune plus whatever it costs for one-piece driveshaft that's worth a damn then you [definitely] don't want the repair bill when something breaks.

I'm certain there are others here that can cover things I've missed.


Craigb79

New Member
May 17, 2020
4
0
1
34
Surrey bc
I think you should just drive it and not worry about how much power it makes.

If you don't want to fork over 5k for a supercharger kit plus and additional 500 or so for a tune plus whatever it costs for one-piece driveshaft that's worth a damn then you [definitely] don't want the repair bill when something breaks.

I'm certain there are others here that can cover things I've missed.
Sorry. But if I wanted to just drive it i would have left it the way it was on the beginning and not dropped the 3k in parts and labor.

I said I didn't want to spend 5k on aprocharger. Doesn't mean I'm not going to pit boost in there. There is other options at better prices.

Cost of custom tune/ dyno not an issue

I just want to know where I should go from here.

If you dont want to answer that then dont reply.
Thanks

..


kiddiccarus

The first widely accepted Tranny
15 Year Member
Dec 24, 2003
1,118
591
133
30 Mins from a Ragged GT
www.angelfire.com
I am by far not a "Have to Have a V8" guy. Everybody knows that and I hate Convertibles. (I own one)

If you want the 350 to the rear, it is easier to sell the V6 and buy the V8.

I have swapped out a 95 V6 engine to an 02 V6 engine. Have done some bolt on's, Changed the rear Axle and other odds and ends. I am sitting at 241 book math right now with what I have.

Check out my build thread for the in depth details on what I have done

Check out "Super Six Motorsports" to see if you like what they have to offer. but I will stand by my first statement. If you are looking for 350 RWHP, sell and buy a V8. It can be done, but it will all be in what you want to invest into the car. Best route I have seen so far is on Super Six. Power pack, forged Internals and pro charger


Noobz347

Stangnet Facilities Maint Tech... Er... Janitor
Admin Dude
Jan 4, 1985
28,971
10,939
224
Box behind Walmart
www.stangnet.com
Sorry. But if I wanted to just drive it i would have left it the way it was on the beginning and not dropped the 3k in parts and labor.

I said I didn't want to spend 5k on aprocharger. Doesn't mean I'm not going to pit boost in there. There is other options at better prices.

Cost of custom tune/ dyno not an issue

I just want to know where I should go from here.

If you dont want to answer that then dont reply.
Thanks

..

Sorry but... You're not the first person to arrive with a dream and no reality. I will also thank you to keep your own counsel as to where and when or how I post. You extended the invitation to the forum. I did not however, seek your advice on how to respond.

If you're looking for 'dreamcatcher' answers, try bookface. If you are looking only for answers that fit squarely on your preconceptions, you should try a notebook. The alternative would be to fully describe the idea that you have in mind and ask questions about its feasibility.


74stang2togo

Oooh! CT!!!
Mod Dude
Mar 7, 2002
7,727
3,588
224
If you dont want to answer that then dont reply.
:pop:


I love it when a new guy shows up with a crazy idea.

I love it even more when they insist on pursuing it even after getting sound advice against it.

I REALLY love it when they start telling people that have been members of this site over a decade and/or RUN THE DAMNED THING what they can and can't post. :rlaugh:

Then they usually keep being silly and get banned and there's no more fun... Once in awhile one of them sticks around, and on even more rare occasions, one sticks around and proves us wrong.

Please be the last kind of that guy... or if you're going to be the first kind of that guy, PUH-LEEZ make it spectacular! :nice:

Last edited:

Craigb79

New Member
May 17, 2020
4
0
1
34
Surrey bc
I am by far not a "Have to Have a V8" guy. Everybody knows that and I hate Convertibles. (I own one)

If you want the 350 to the rear, it is easier to sell the V6 and buy the V8.

I have swapped out a 95 V6 engine to an 02 V6 engine. Have done some bolt on's, Changed the rear Axle and other odds and ends. I am sitting at 241 book math right now with what I have.

Check out my build thread for the in depth details on what I have done

Check out "Super Six Motorsports" to see if you like what they have to offer. but I will stand by my first statement. If you are looking for 350 RWHP, sell and buy a V8. It can be done, but it will all be in what you want to invest into the car. Best route I have seen so far is on Super Six. Power pack, forged Internals and pro charger

I have checked them out. But the thing is I am not sure what order I should be doing my mods.

Investing money is not the issue. But I'm not rich so will be a slow process.
I'm looking for a "road map" if you will.

I was considering dropping a 4.6 in. But I wasn't sure if I would need to replace the dual exhaust I just put in with a gt exhaust. I assumed yes. It makes sense that I would have to.


kiddiccarus

The first widely accepted Tranny
15 Year Member
Dec 24, 2003
1,118
591
133
30 Mins from a Ragged GT
www.angelfire.com
Paraphrased: BY Kiddiccarus

2007 V6 with a 4.0L
Torque240 ft-lbs. @ 3500 rpm
Base engine size4.0 l
Horsepower210 hp @ 5300 rpm
Turning circle33.4 ft.

Installed:

Air Raid Cold Air Intake: Probably This Link Here
2008 GT 8.8 Rear End with 3.33:1 Ratio
Pypes Dual Exhaust

Tentative Goal is to get as close to 350 RWHP as possible
OK. Please Answer these questions.

  1. Is this car a Daily Driver or a Secondary Play Thing
  2. Money is ALWAYS A FACTOR or we would all be driving a Special Edition Stang. So, in reality what is the budget here?
  3. What are you doing with the car right now? I am asking, is it sitting waiting for a wrench to be turned or are you driving it to get your groceries and it can not be without power or an engine for a month?
  4. Are you looking to make Money off this build in a well .......... or are you doing this build to make yourself fell happy and have a sense of accomplishment?
  5. What is your Knowledge in engines and doing the work yourself?

In my build, I am making the best version of a daily driver that I have envisioned in my own mind. When I run into troubles, this community helps me. I in turn share my knowledge to help others who embark on the V6 route to get them as close to their goal that I can. (I am not done with my build yet by any means)

As for a road map, we can do that, but I need the questions answered because the road map suggestions will hinge upon them.


Craigb79

New Member
May 17, 2020
4
0
1
34
Surrey bc
OK. Please Answer these questions.

  1. Is this car a Daily Driver or a Secondary Play Thing
  2. Money is ALWAYS A FACTOR or we would all be driving a Special Edition Stang. So, in reality what is the budget here?
  3. What are you doing with the car right now? I am asking, is it sitting waiting for a wrench to be turned or are you driving it to get your groceries and it can not be without power or an engine for a month?
  4. Are you looking to make Money off this build in a well .......... or are you doing this build to make yourself fell happy and have a sense of accomplishment?
  5. What is your Knowledge in engines and doing the work yourself?

In my build, I am making the best version of a daily driver that I have envisioned in my own mind. When I run into troubles, this community helps me. I in turn share my knowledge to help others who embark on the V6 route to get them as close to their goal that I can. (I am not done with my build yet by any means)

As for a road map, we can do that, but I need the questions answered because the road map suggestions will hinge upon them.
1 car is my weekend ride but will be used on the streets
2 I'm not rich but of course if money was no object I would not have bought the car I did. I'd have to do thing one thing at a time or whatever. But I'd say 10-15 k over time is reasonable.
3) car sits in parking space most days and I take transit to work...its my weekend car
4) doing this to make myself happy. And if I get it to where I want it I'll probably keep it forever lol
5)personal knowledge is minimal. But have lots of family willing to help.i would not shy away from professional help if needed. Also I just prefer to have the peice of mind


kiddiccarus

The first widely accepted Tranny
15 Year Member
Dec 24, 2003
1,118
591
133
30 Mins from a Ragged GT
www.angelfire.com
Since it is not a Daily Driver and your knowledge is in the learning stage which is 100% OK we are all learning. We can use what you already stated as a starting point.

Some of the Mods that I will be talking about are not to increase HP but to create a Stable Base and Foundation for what you want to have in the end result. Only YOU can decide in the end if the suggestion will be something which you want to add into your build.

Suggestions: (In Order)

BUY THIS FIRST: You will need it to figure out what the hell Ford did at times that makes no sense in what actually needs to be done. Trust me on this one.


Rear End:
  1. Make sure the GT rear end has limited slip in it.If it does not, you may want to consider getting a LSD Carrier.
  2. Upgrade the differential cover plate to a girdle.
  3. Torque box kit.
  4. Quality Shocks and Struts all around (Quad Shocks if you are not running a wheel that cant use them on the rear)
  5. Upper and Lower Control arms that will allow you to safely hit 400RWHP (I have these on mine)
  6. YOU DO NOT NEED COBRA BRAKES!!!!
Drive line:
  1. Transmission, look into exactly what you have. Manual/Automatic. Look at what it can handle as it sits. If an upgrade is not needed, then no need.
  2. Aluminum Drive Shaft
  3. Manual Trans. If you are not going to Autocross, Drag, Etc for money. You wont ever need anything more than a Stage II clutch kit and probably wont need that.
  4. Automatic Trans, check the rating for torque and hp. I never owned an Automatic in a Mustang so I am not the best at upgrades here.
Engine:
  1. Decide on if you are going to swap engines or build the one in the car now
  2. If the engine that you are building is the one inside the car right now.
    1. Are you going to remove it and build it until complete?
    2. Are you going to upgrade and use bolt on's until you have to remove it to complete the build?
  3. If the engine that you are building is not the one inside the car right now. (Advantage: Everything can be done prior to install)
    1. Used? The a rebuild kit is suggested. (You said you can get help in the work)
    2. Determine if you are going with forged internals, if this is a yes. Do this when you are rebuilding the engine.
    3. If the end result of this build will include a Pro-Charger, make sure that all decisions in the build are leading toward that. Heads, Cam, Lifters, Rockers, Headers, Porting, Polishing, Etc.
    4. Install, Test, Tune, Live Life Happy.
Body: (My Sole Opinion)
  1. Do not take anyone's Advice on what YOU want your car to look like.
  2. I prefer the stock look so that nobody is trying to bother me at a street light
  3. Ask for suggestions on things that work for others and make an informed decision on what you will use.
  4. If you change the hood for the Pro-Charger. Measure and don't try to go too high, it will jack up your visibility.

  • Like
Reactions: Craigb79

74stang2togo

Oooh! CT!!!
Mod Dude
Mar 7, 2002
7,727
3,588
224
Make sure the GT rear end has limited slip in it.If it does not, you may want to consider getting a LSD Carrier

Quality Shocks and Struts all around (Quad Shocks if you are not running a wheel that cant use them on the rear)

YOU DO NOT NEED COBRA BRAKES!!!!


If the end result of this build will include a Pro-Charger, make sure that all decisions in the build are leading toward that. Heads, Cam, Lifters, Rockers, Headers, Porting, Polishing, Etc.
All Mustang GTs built since 1987ish have limited slip.

S197s don't have quad shocks.

Cobra brakes don't fit S197s.

The engine has two cams (with four timing chains, including one on the back of the engine), no lifters, and no rocker arms.

  • Like
Reactions: kiddiccarus
Thread starter Similar threads Forum Replies Date
T 04 Stock GT want to upgrade cams 1996 - 2004 SN95 Mustang -General/Talk- 1
U Want To Upgrade A 2007 Base Model With Single Cd Player Mustang Sound & Shine All 0
killer5.0 want to do a brake upgrade and i want new rims...should i swap to 5-lug? what do i.. Fox 5.0 Mustang Tech 20
StreetDreamsGT Brake upgrade info.... I want a rather cheap method for reliable improved stopping Fox 5.0 Mustang Tech 16
04GTMustang wanting to upgrade the blower 1996 - 2004 SN95 Mustang -General/Talk- 21
C SUSPENSION upgrade info wanted 2005 - 2014 S-197 Mustang -General/Talk- 6
F need some help, new want to know some cheap upgrades SN95 4.6L Mustang Tech 2
old_blue 112k on the clock, want to upgrade, time to rebuild? 1996 - 2004 SN95 Mustang -General/Talk- 0
C pony is going in for upgrade. anyone want the old parts? 2005 - 2014 S-197 Mustang -General/Talk- 2
B Want to upgrade to a 4bl, need some suggestions Classic Mustang Specific Tech 66
J Already 5 lug now I want to upgrade brakes Fox 5.0 Mustang Tech 3
revedup 5.0 217,000 miles want to upgrade!! Fox 5.0 Mustang Tech 19
old_blue thinking I want to upgrade to this dash piece, how does it fit?? Fox 5.0 Mustang Tech 9
just4bob50 want to upgrade my valve springs Fox 5.0 Mustang Tech 0
12sec67 for those who want to upgrade to A/C Classic Mustang Specific Tech 4
6 Want to upgrade/update my '66 GT brakes - ideas? Classic Mustang Specific Tech 7
N Wanting to upgrade throttle body, any suggestions? +I have some other questions here SN95 4.6L Mustang Tech 0
M Wanting to upgrade to 8.8 or 9 rear end. Classic Mustang Specific Tech 2
D want to upgrade brakes but have 15inch wheel Fox 5.0 Mustang Tech 17
K want to upgrade 83 brakes with 92 brakes Fox 5.0 Mustang Tech 1
chicks-dig-it want to upgrade, can't drive stick SVT Tech Forum 9
downsouthman1 $2000! & I want to upgrade my brakes, SN95 4.6L Mustang Tech 25
A WTB/Trade Stock Mustang 5.0 cam wanted Engine and Power Adder 0
W WTB/Trade Wanted supercharger kit for 1995 GT 5.0 Engine and Power Adder Parts 0
T Stationed Overseas and Want to Restore 66 Stang for Wife for 25th Anniversary 1965 - 1973 Classic Mustangs -General/Talk- 4
B Forced Induction 1986 5.0 wanting to turbocharge Fox 5.0 Mustang Tech 0
A Mustang gt 2001 mach 460, want a double din with Apple CarPlay The Welcome Wagon 3
P WTB/Trade Wanted 1985-1993 5.0 Mustang Fox Body Mustangs For Sale (1979-93) 0
H Suspension help wanted Fox 5.0 Mustang Tech 18
2Blue2 Help I want to put this T5 in our Cobra II 1974 - 1978 Mustang II Talk & Tech 104
7991LXnSHO Want to put EFI on a 6 Cyl. What System to get? Digital Self-tuning Forum 5
S vehicle shut of and does not want to start up again 2005 - 2009 Specific Tech 0
0 4.6 SOHC Engine Swapper Wanted $$ 1996 - 2004 SN95 Mustang -General/Talk- 0
R Expired Want to buy I-6 Engine Mounts 69-72 250 I6 Drivetrain Parts 1
S WTB/Trade Wanted 2013-2014 GT500 S197 Mustangs For Sale (2005-14) 0
R WTB/Trade WANTED STEEDA SPYDER wheel 20x11 w/machined face & lip Wheels Tires Brakes 0
C how to change the ignition on a mustang I just want to know I've been looking around and I can't find it for a specific year and Mom for a mustang II 1974 - 1978 Mustang II Talk & Tech 9
E WTB/Trade WANT TO BUY: ALMOND FOXBODY Fox Body Mustangs For Sale (1979-93) 0
E I want to go faster 1979 - 1995 (Fox, SN95.0, & 2.3L) -General/Talk- 62
K WTB/Trade WANTED: Late 1980s Mustang Times Magazines Other Classifieds 0
S SOLD Trade 1957 Chevrolet Nomad for 2013-2014 GT500 S197 Mustangs For Sale (2005-14) 6
G Want to turbo my V6 2001 mustang 1996 - 2004 SN95 Mustang -General/Talk- 8
seanw WTB/Trade Wanted: Tailgate for 1965 Ford Ranchero Other Classifieds 0
B WTB/Trade Wanted to Buy. 87-93 coupe rear seats. Interior Exterior Parts 1
G Engine 1994 doesnt want to accelerate past 3000 1994 - 1995 Specific Tech 3
ndfox92 Fox does anyone have a victor efi intake for a 351w they want to part with? 1979 - 1995 (Fox, SN95.0, & 2.3L) -General/Talk- 0
J Want to possibly swap out a 302 for a 351W Fox Engine Swaparoo 1
John Dirks Jr The I don’t want to sell it price 1979 - 1995 (Fox, SN95.0, & 2.3L) -General/Talk- 13
7 WTB/Trade 1973 Mach 1 Louvers wanted! Interior Exterior Parts 0
L I honestly want your opinions. 1979 - 1995 (Fox, SN95.0, & 2.3L) -General/Talk- 18
Similar threads
