Engine Svo Turbo Bad ?

Discussion in '2.3L (N/A & Turbo) Tech' started by Crazyives90, May 25, 2014.


  1. Crazyives90

    Crazyives90 Member

    Joined:
    May 25, 2014
    Messages:
    16
    Likes Received:
    4
    Trophy Points:
    13
    84 svo... T-3 gasket blew to a unknown bolt broken on the flange instelf.. I fear the gasket shot into the turbo... Now its all back togather and I her a constant scraping noise near the turbo

    Attached Files:

    #1
  2. fess40

    fess40 Founding Member

    Joined:
    Nov 17, 2001
    Messages:
    277
    Likes Received:
    2
    Trophy Points:
    19
    Location:
    Paris, Illinois
    Pull the house off the front of the turbo and check for shaft play. Make sure it spins freely.
    #2
  3. madspeed

    madspeed Colonel Mustard Mod Dude Founding Member

    Joined:
    Nov 30, 1999
    Messages:
    8,421
    Showcase:
    9
    Albums:
    1
    Likes Received:
    1,224
    Trophy Points:
    174
    Location:
    a van down by the river
    Gasket may have gotten lodged inside the turbo vanes. Pop your inlet hose off and take a peak see
    #3
  4. madspeed

    madspeed Colonel Mustard Mod Dude Founding Member

    Joined:
    Nov 30, 1999
    Messages:
    8,421
    Showcase:
    9
    Albums:
    1
    Likes Received:
    1,224
    Trophy Points:
    174
    Location:
    a van down by the river
    err, thinking about this, what gasket blew? I would assume where the turbo mounts to the exhaust piping, that gasket wouldve blown right into your exhaust
    #4
  5. Crazyives90

    Crazyives90 Member

    Joined:
    May 25, 2014
    Messages:
    16
    Likes Received:
    4
    Trophy Points:
    13
    It was the t3 flange gasket .. worst part was it was a metal gasket not one of those metallic ceramic plastic ones... I say worst part cause I believe to what happened was it got lodged in there and bent the shaft.... There is play and I think it made the turbine rub from shaft play
    #5
  6. KhanTyranitar

    KhanTyranitar Member

    Joined:
    Apr 21, 2011
    Messages:
    93
    Likes Received:
    1
    Trophy Points:
    9
    Extremely unlike that the gasket would have gotten in. That area is under pressure, so if any pieces broke free, they would have blown out, no possibility of getting sucked in. The issue you are having may very well be turbo failure, but I doubt its related to the gasket.
    #6
  7. 65ShelbyClone

    65ShelbyClone Founding Member

    Joined:
    Sep 9, 2000
    Messages:
    4,728
    Likes Received:
    14
    Trophy Points:
    69
    Location:
    Antelope Valley, SoCal
    You need to pull the turbo off and remove the housings to see what is really going on. I bet the bearings were already spent. It's highly unlikely that the gasket got sucked into the turbine because turbine drive pressure is at least twice the boost pressure. At 14psi there is about 30psi inside the manifold pushing the gasket pieces away from the turbo.
    #7
  8. Crazyives90

    Crazyives90 Member

    Joined:
    May 25, 2014
    Messages:
    16
    Likes Received:
    4
    Trophy Points:
    13
    Yeah it's the bearings ... They were spent, also causing oil to get through . In need of a new turbo ... This happened while the car was at a idle in the parking lot. So I know it was not really cooking. It was bound to happen.
    #8
