    I just drug my ass in from the driveway. That engine install had to be just about the hardest damn thing I've done in a while.

    Car is 2 feet in the air,....I have the engine and trans bolted together w/ only the starter bolted on as far as accys go. I set the chain to allow the trans to just hang a a slight down angle.

    The first obstacle: The combo weighs a ton!! trying to drag the heavy assed combo up onto the slab where the car is proves beyond me. Fortunately,..my 15 year old is around to help. With him pushing,...and me pulling,...I get it up on the slab,

    [​IMG]
    while this doesn't show how high the slab was, suffice it to say that I had to drag the damn mess up a 7" rise. It does show how clean I've managed to get everything up front.

    [​IMG]

    The next hurdle comes from the fact that the damn engine is huge! And w/ the trans hooked to it, I had to jack the thing to the 13th floor to get it high enough to clear the radiator saddle.
    The problem was,..at that high angle the engine would not tip,..so I couldn't tip the tail shaft into the trans tunnel.

    After readjusting the hoist lift point to extend the top another 6" to allow more height ( while simultaneously dropping the load rating from 1 ton to 3/4 ton,...I send the whole mess up to the roof again.
    It's still a son of a bi tch. The hoist cylinder is against the bumper, and the engine will not go any further forward,....I pi ss and moan,...yank and tug,..until I decide to get a motorcycle tie down, and ratchet the tail shaft down into the tunnel.

    ( keep in mind,..that all of this is being supported by a 199.00 harbor freight engine hoist,....the engine weighs a bazillion lbs,....and now I'm adding additional stress by ratcheting the tailshaft down.)

    I get it only as far as the harmonic balancer,..it was now hanging up on the radiator saddle. It still will not go,..and now it's kinda past the point of no return.
    Some more pi ssing, some more moaning, yanking and tugging,.both me and my son pushing for all we're worth, and now it's dark. Finally it slides past the saddle. ( but not before scratching it, and the firewall above the tunnel opening though):mad:

    I finally got it,..but it was the WORST of the 20 or so engine installs I've done in my life. I will NOT be doing that again soon.:fuss:

    #1
  2. Shakerhood

    Shakerhood Well-Known Member

    Joined:
    Oct 29, 2004
    Messages:
    2,879
    Likes Received:
    50
    Trophy Points:
    59
    Location:
    Ohio
    Sounds pretty miserable, at least you got it in.

    #2
  3. mikestang63

    mikestang63 Mustang Master

    Joined:
    Aug 28, 2012
    Messages:
    4,048
    Showcase:
    20
    Albums:
    1
    Likes Received:
    1,146
    Trophy Points:
    154
    Location:
    In the garage
    Curious- why are the headlights out?

    #3
  4. madmike1157

    madmike1157 the humor is still lost on me SN Certified Technician

    Joined:
    Nov 30, 1999
    Messages:
    3,944
    Albums:
    1
    Likes Received:
    1,031
    Trophy Points:
    154
    Location:
    Birmingham, al
    They were hazed pretty badly,...I've yet to clean the really clean the paint,...and I'm gonna run a buffer over it after that,..so I left them out after fixing them.

    #4
  5. madmike1157

    madmike1157 the humor is still lost on me SN Certified Technician

    Joined:
    Nov 30, 1999
    Messages:
    3,944
    Albums:
    1
    Likes Received:
    1,031
    Trophy Points:
    154
    Location:
    Birmingham, al
    As a matter of fact it was pretty miserable. But that was the hurdle that was standing in the way to really getting moving putting it back together. Now that it's done,.. I can bit ch about other things.

    #5
  6. Noobz347

    Noobz347 Stangnet Facilities Maint Tech... Er... Janitor Admin Dude

    Joined:
    Jan 5, 1985
    Messages:
    20,362
    Showcase:
    59
    Albums:
    8
    Likes Received:
    2,595
    Trophy Points:
    174
    Location:
    Box behind Walmart


    A KR style hood on an 03/04 Cobra. :chin

    Don't think that's been done before. Wonder what it would look like. :scratch:

    Oh, uh.... Please continue.
    :leaving:

    #6
  7. RacEoHolic330

    RacEoHolic330 I like to dress like a pretty girl SN Certified Technician

    Joined:
    Mar 5, 2003
    Messages:
    3,538
    Likes Received:
    746
    Trophy Points:
    153
    Location:
    Allentown, PA
    Sounds like you need to invest in a load leveler. I think mine was $40. Worth their weight in gold. Although, it probably would have made your situation worse because it really cuts down the amount of height you can get out of the cherry picker.

    #7
  8. 85_SS_302_Coupe

    85_SS_302_Coupe it sucks (I know) to be on the receiving end

    Joined:
    Nov 11, 2003
    Messages:
    283
    Likes Received:
    888
    Trophy Points:
    173
    Location:
    Northern KY
    I feel your pain. I haven't pulled/installed mine too many times, I think maybe 3 times but even my straight forward 302 has been a PITA a couple of those times. I have this weird issue where my engine sits funny in my K member, we never could figure out what the problem was. It sat lower on the passenger side and the end result was the header hit the steering shaft really bad, so we made a 1/4 inch thick steel shim to go between the motor mount and K member on that side and it solved the problem. We tried different motor mounts and inspected the K and nothing made a difference.

    #8
  9. 90lxcoupe

    90lxcoupe Mustang Master

    Joined:
    Oct 8, 2003
    Messages:
    3,450
    Likes Received:
    179
    Trophy Points:
    84
    Sounds like when it goes back in the motor and trans should be separated.

    #9
    FiveLiterSN95, stangboy and srtthis like this.
  10. srtthis

    srtthis the guy doing it does every local racers rear end

    Joined:
    Jul 4, 2009
    Messages:
    3,925
    Likes Received:
    478
    Trophy Points:
    114
    Location:
    in the shop working!
    atleast the back half of the bell housing and trans should be taken off... the front half clutch and flywheel can stay

    #10
  11. madmike1157

    madmike1157 the humor is still lost on me SN Certified Technician

    Joined:
    Nov 30, 1999
    Messages:
    3,944
    Albums:
    1
    Likes Received:
    1,031
    Trophy Points:
    154
    Location:
    Birmingham, al
    Yeah, that's the way it should'be been done. I was just trying to avoid the under car hernia from trying to muscle it in laying on my back.

    #11
    stangboy likes this.
  12. srtthis

    srtthis the guy doing it does every local racers rear end

    Joined:
    Jul 4, 2009
    Messages:
    3,925
    Likes Received:
    478
    Trophy Points:
    114
    Location:
    in the shop working!
    thet T56 isnt THAT heavy....





































    ok maybe it is...

    #12
    stangboy likes this.
  13. rd

    rd Founding Member

    Joined:
    Jan 12, 2000
    Messages:
    3,427
    Likes Received:
    19
    Trophy Points:
    59
    Location:
    Ocean Springs MS
    Sounds like it was a pain. I have only done a Fox, 302 and C4 together, once, and it worked using just a come along from a bolt above the garage door. Had to move the car back and forth... Engine or trans only since then.

    Just did the engine out and in for my 66 Chevelle, engine only. On my downhill sloped driveway. Almost a bigger pita. There is not enough room for the bellhousing to engine bolts w/o dropping the trans. Much cussing, and I expected it!

    It helps to push the hood up as far as possible with a pipe or stick. An engine tilter is worth it's weight in gold!

    #13
  14. stangboy

    stangboy Founding Member

    Joined:
    Aug 31, 1999
    Messages:
    3,552
    Likes Received:
    102
    Trophy Points:
    84
    Location:
    New Orleans, LA
    I absolutely HATE pulling/installing engine and trans together. IMO its not worth the headache. I've helped others do and swore I'd never do it on ANY of my cars.

    #14
  15. Shakerhood

    Shakerhood Well-Known Member

    Joined:
    Oct 29, 2004
    Messages:
    2,879
    Likes Received:
    50
    Trophy Points:
    59
    Location:
    Ohio
    Next time you can pull a Shelby and jack the rear of the car up while installing.

    #15
    Maryland Stang and 5.0Droptop like this.
  16. 85_SS_302_Coupe

    85_SS_302_Coupe it sucks (I know) to be on the receiving end

    Joined:
    Nov 11, 2003
    Messages:
    283
    Likes Received:
    888
    Trophy Points:
    173
    Location:
    Northern KY


    I helped a buddy put one in...easily the heaviest trans I've ever picked up. I've rolled T5's over on my chest and put them in by myself...I wasn't even going to attempt that with the T56.

    #16
  17. stangboy

    stangboy Founding Member

    Joined:
    Aug 31, 1999
    Messages:
    3,552
    Likes Received:
    102
    Trophy Points:
    84
    Location:
    New Orleans, LA
    I borrowed a transmission jack from a friend and it became my new best friend when dealing with my Tremec 3550 and will continue being my best friend when I install my new TKO 600. I don't even bother with T5s anymore so I can't just muscle a tranny up there anymore.

    #17
  18. David Pepiton

    David Pepiton Active Member

    Joined:
    Dec 18, 2011
    Messages:
    677
    Likes Received:
    68
    Trophy Points:
    49
    Location:
    Laveen, Arizona
    I thought I saw some cuss words in there but I know they are banned so i had to do a double take and realized they were two separate words clearly NOT in violation of stangnet policy. sarcasm if you couldnt tell

    in other words im glad you had fun mike at least you had a helper. at least the cars looking great and the scratches are nothing a little touch up can handle im sure.

    #18
  19. 85_SS_302_Coupe

    85_SS_302_Coupe it sucks (I know) to be on the receiving end

    Joined:
    Nov 11, 2003
    Messages:
    283
    Likes Received:
    888
    Trophy Points:
    173
    Location:
    Northern KY
    I've put my 3550 in the same was as a T5 but it sucks major ass and takes another set of hands to start the bolts. I don't think the 3550 is quite as heavy as the T56 though.

    #19
  20. Coops79

    Coops79 Member

    Joined:
    May 15, 2013
    Messages:
    10
    Likes Received:
    1
    Trophy Points:
    14
    Location:
    Calgary
    Wouldn't have taking the hood off made the job slightly more easier?
