How To Tell If My Head Is A Terminator?

Discussion in 'SVT Tech Forum' started by shaunspengler, Jun 19, 2012.


  1. shaunspengler

    shaunspengler Member

    Joined:
    Mar 30, 2011
    Messages:
    51
    Likes Received:
    1
    Trophy Points:
    8
    Location:
    west covina
    hi as you can tell ive just put a down payment on a cobra terminator engine. today i gave the guy 350$ and he gave me one head. i was wondering if anyone could tell me or give me any info so i could see if these are 03/04 heads/ engine. all i can say is i know its aluminum and its got 4 valves and 2 cams. i can take pictures if that will help.

    #1
  2. hotcobra03

    hotcobra03 Active Member

    Joined:
    Nov 30, 1999
    Messages:
    1,000
    Likes Received:
    1
    Trophy Points:
    39
    Location:
    poteet,tx
    pic
    ,casting number on side.
    both cam part numbers
    than you will know

    #2
  3. Thomas Morrison

    Thomas Morrison Member

    Joined:
    Feb 3, 2013
    Messages:
    37
    Likes Received:
    2
    Trophy Points:
    8
    Location:
    FL SPACE STATION (jk)
    casting number.

    The 03-04 heads are the same as the 99s
    There was an update on them in late 03 or 04 where they went to 8 thread spark plug holes.

    #3
  4. Noobz347

    Noobz347 Stangnet Facilities Maint Tech... Er... Janitor Admin Dude

    Joined:
    Jan 5, 1985
    Messages:
    20,331
    Showcase:
    59
    Albums:
    8
    Likes Received:
    2,587
    Trophy Points:
    174
    Location:
    Box behind Walmart
    If it looks anything like this:


    [​IMG]

    Then you have a Terminator head.

    Your welcome.

    #4
  5. Gearbanger 101

    Gearbanger 101 Straight Outta Locash Super Mod

    Joined:
    Aug 11, 2002
    Messages:
    14,480
    Likes Received:
    949
    Trophy Points:
    164
    Location:
    Ontario, Canada
    That would be incorrect.

    The '03's are a differnt casting numbers for starts. Dimensionally with large rectangular exhaust ports, larger volume intake ports with reshaped and raised port roof with a revised short turn radius. The heads were also of an over all higher quality casting than previous DOHC heads, which netted better finish and geneally higher out of the box flow ratings.

    The revision took place in mid-03 to solve cooling issues and were identifyable with a blue paint mark on the drivers side casting.

    #5
  6. Thomas Morrison

    Thomas Morrison Member

    Joined:
    Feb 3, 2013
    Messages:
    37
    Likes Received:
    2
    Trophy Points:
    8
    Location:
    FL SPACE STATION (jk)
    Oooo really?

    Differences? We are all down to learn. I have a set of 2001 heads and a set of 04 heads next to each other and the flow characteristics look identical. The only thing I can think of is the cooling passages and the spark plug threads

    #6
  7. Gearbanger 101

    Gearbanger 101 Straight Outta Locash Super Mod

    Joined:
    Aug 11, 2002
    Messages:
    14,480
    Likes Received:
    949
    Trophy Points:
    164
    Location:
    Ontario, Canada
    See my edit above. Just because they look the similar from the outside, doesn't mean they're the same head.

    Nearly all 5.0L 302 OHV heads looked alike visually thoughout the 80's as well...but we all know some were better than others.

    #7
  8. Noobz347

    Noobz347 Stangnet Facilities Maint Tech... Er... Janitor Admin Dude

    Joined:
    Jan 5, 1985
    Messages:
    20,331
    Showcase:
    59
    Albums:
    8
    Likes Received:
    2,587
    Trophy Points:
    174
    Location:
    Box behind Walmart
    ...I've never been able to bench-flow heads by merely looking at them. o_O That generally requires some pretty specialized equipment.

    In other words: How the heads look is irrelavant.

    #8
  9. Thomas Morrison

    Thomas Morrison Member

    Joined:
    Feb 3, 2013
    Messages:
    37
    Likes Received:
    2
    Trophy Points:
    8
    Location:
    FL SPACE STATION (jk)
    Interesting. I would like to see the CFM numbers between the two heads. I put the 03-04 heads on my 2001 but i dont have dino. numbers so no comparison. :(

    At least I know I did the right thing.

    #9
  10. Thomas Morrison

    Thomas Morrison Member

    Joined:
    Feb 3, 2013
    Messages:
    37
    Likes Received:
    2
    Trophy Points:
    8
    Location:
    FL SPACE STATION (jk)
    Lol I have awesome analizing eyes... not
    I know you can't but Ive never seen the numbers so its all I have. My point was its really hard to SEE the difference like he was asking for tips on

    #10
